DS-25 Pump for Frac Emulsion Industrial Cleaning

DS-25 Pump for Frac Emulsion Industrial Cleaning

The DS-25 pump is a single acting triplex reciprocating plunger pump.
  • Model :

    DS-25
  • Type :

    Plunger Pump
  • Stroke :

    60
  • Cylinder Diameter :

    25
  • Flow :

    45
  • Pressure :

    21
  • Shipping Port :

    Shanghai Port, China
  • Warranty :

    12 Months

The DS-25 Emulsion pump is a single-acting triplex reciprocating plunger pump, which is independently designed, developed and manufactured by the company and integrates advanced domestic and foreign technologies. It can be used for Oilfield, Coal Mining, Industrial Cleaning and etc.



Liquid end and power end designs of various materials and structural forms can be provided according to the medium composition of the application scenario, with various structural forms such as built-in reduction size or external reduction gearbox. The plunger sealing forms mainly include packing seals, polymer seals and other sealing structures adapted to the working conditions.



Features:

1.  The wearing parts have long life, high reliability and beautiful overall appearance.

2.  With vibration sensing intelligent feedback unattended system.

3.  It can be equipped with forced lubrication system, oil temperature alarm, oil pressure alarm, flow pressure monitoring.

4.  It has hydraulic, motor, diesel engine and other drive forms.



Technical Parameters and Specifications:

Type Horizontal Triplex Reciprocating Single Acting Plunger Pump
Model DS-25
Stroke Length (mm) 60
Liner Diameter (mm) 25
Pump Speed (r/min) 500
Flow (L/min) 45
Pressure ( Mpa) 21
Rated Power (KW) 18.5
Outline Dimension (mm) 850*660*360
Weight (kg) 220
