The Lubrication of Elephant Mud Pump

September 25, 2023

Lubrication of mud pump is very important. In order to ensure that pumps can continue to work normally and reduce wear and tear of moving parts, regular lubrication should be carried out according to the table below. After 80 hours of operation, the pump body must be cleaned and changed, and then oil must be changed every 200 hours.

Lubrication of hydraulic motor mud pumps / electric mud pumps:

No.#	Lubricating location	Lubrication Oil (grease) Brand	Remarks
1	Gears and bearings in the Crankshaft case	L-AN46 oil for total loss system	All the time

Lubrication of extended mud pumps:

No.#	Lubricating location	Lubrication Mode and Lubricating Oil Varieties	Lubricant replacement period	Lubricating oil consumption
1	Gears and bearings in the Crankshaft case	Splash lubrication L-AN46 oil for total loss system	After 80 hours of operation, the pump body must be cleaned and changed, and then oil must be changed every 200 hours.	Indicate position according to oil mark
2	Reducer	Splash lubrication L-AN46 oil for total loss system	After the new pump works for 80 hours, the gearbox must be cleaned and replaced with oil, and then the oil must be changed every 200 hours.	Indicate position according to oil mark
3	Universal spline and crosshead parts	Pressure injection of lithium grease SY1412-75 with oil gun	Timely note, irregular	Appropriate amount

The above methods are only for mud pump system of Elephant brand. Some models may be difference, please contact us for more details.
